Digital Cutting Machine

Modle

UNIC-0814    UNIC-1209    UNIC-1512    UNIC-1616(R)    UNIC-1618(R)    UNIC-1620(R)    UNIC-2516(R)    UNIC-2518(R)    UNIC-2520(R)

Features

Han-Bond independent research and developed CAM software prevents inner angles break cutting to recover graphic outline maximally .

The modular tools make it easy to specific cutting needs. Define your production requirements, and select the building blocks that will make up the perfect configuration for you. Additions  and upgrades are possible any time .

Servo motor drive , high precision ,  low noise , long life .

Intelligent automatic identification and optimization of the file data .

Any type of  notch will  be automatically  converted to  punching  data .


  1. Garment industry


2.Furniture industry


3.Automotive industry

Parameters

Modle

UNIC-0814

UNIC-1209

UNIC-1512

UNIC-1616(R)

UNIC-1618(R)

UNIC-1620(R)

UNIC-2516(R)

UNIC-2518(R)

UNIC-2520(R)

Feeding system

Discontinuous feeding

With R means continous feeding function,without R means discontinous feeding

Maximum Cutting width

800*1400mm

1200*900mm

1500*1200mm

1600*1600mm

1600*1800mm

1600*2000mm

2500*1600mm

2500*1800mm

2500*2000mm

Maximum Cutting Speed

1500mm/s

Precision

±0.1mm

Maximum Cutting Thickness

25mm,thicker materials can be customized models

Transmission Port

Serial Port、Network Port

Data Format

HP-GL、DXF、PLT

Cutting Material

Carbon fiber, composite material, EVA, XPE, leather, cloth, PVC foam board, KT board, MDF
Cardboard, carton, silk ring, wool-like, self-adhesive, asbestos gasket, film, canvas, etc.

Power Supply

220V±20% / 50~60Hz

380V / 50~60Hz

380V / 50~60Hz

Air Pump Power

2*1.5KW

7.5KW

9KW

Equipment Power

2.2KW

Meidia Adsorption

Vacuum

Environment

Temperrature 0°- 40°   Humidity 20% - 80%

UNIC Size(Length*Width*Height)

2980*2145

*1200mm



2380*1645*

1200mm

2680*1945*

1200mm

2780*2460*1200mm

2780*2660*1200mm

2780*2860*1200mm

3680*2460*1200mm

3680*2660*1200mm

3680*2860*1200mm

UWP Size

\

\

\

1200*1890*840mm

1200*2090*840mm

1200*2290*840mm

1200*1890*840mm

1200*2090*840mm

1200*2290*840mm

ARD Size

\

\

\

840*2030*845mm

840*2230*845mm

840*2430*845mm

840*2030*845mm

840*2230*845mm

840*2430*845mm

UNIC+UWP+ARD

\

\

\

4820*2460*1200mm

4820*2660*1200mm

4820*2860*1200mm

5720*2460*1200mm

5720*2660*1200mm

5720*2860*1200mm

UNIC Package Size

1633*2215

*610mm



2000*1640*610mm

2000*1940*610mm

2880*2100*900mm

2880*2300*900mm

2880*2500*900mm

5720*2100*900mm

5720*2300*900mm

5720*2500*900mm

ARD Package Size

\

\

\

1000*2200*500mm

1000*2400*500mm

1000*2600*500mm

1000*2200*500mm

1000*2400*500mm

1000*2600*500mm
