One-Click Digitizer

Model

SDigit-1812 SDigit-2412


Features

  • One-click detect patterns, fast speed, high precision;


  • Black and white two backgrounds, identify patterns, fabrics,models and other samples;


  • Compatible with all CAD software;


  • Suitable for garment, shoes, bags,furniture,automotiveinterior and other industries.

Parameters

ModelSDigit-1812SDigit-2412
Scan Speed 3300mm/min
Tack Time43s57s
Scan Accuracy0.15mm
Scan Area1800*1200mm2400*1200mm
Data FormatDXF、PLT、PDF
Power SupplyAC110/220V +20%/50~60Hz 180W
Machine Size2300*1368*970mm2900*1368*970mm
Package Size2400*1420*510mm3000*1420*510mm
Gross Weight290kg330kg
Net Weight192kg218kg
